Andrew's Mental Model of React

November 18, 2020


SAGE3: Smart Amplified Group Environment
SAGE3: Smart Amplified Group Environment

Overview

Here I discuss my mental model of React and how it scales to the architecture of large applications like SAGE3. This will evolve as I have new thoughts or as I find better ways to articulate this information.

Definitions

Some terms like "state" or "instance" are overloaded and could be interpreted in multiple ways. Below are definitions about how I primarily use these terms in this context.

  • state - referring primarily to React State, not the broader idea of stateful behavior which may be external to React (which we are going to implement in SAGE3 and is separate but related -- will get to this later)
  • instance - not an "instance" of a class like in Object Oriented Programming (OOP), but an instance of a component in the sense of an occurrence at a specific place in the DOM tree
  • app - A SAGE app: functionality contained within a single window, not the React application

Props and State

A good way to frame the discussion about application and component architecture is to make sure we think in terms of the model of React: components are pure representations of props + state. Additionally, React is declarative. Your components aren't specifying how the DOM is updated, but only a description of what it looks like when rendered. React handles the question of how it gets rendered.

A React component is a description of how a piece of a UI will look given Props passed to it and the component's State.

In the most simplistic form, you can have a component which is stateless. This means that your component is a completely pure representation of props, or parameters, passed to it and contains no state, itself. You can see this idea in functional programming: given some input to the function, the function produces an output which is always consistent and does not mutate the input data (purity/immutability). If the component is rendered any number of times any combination of different props, it doesn't matter what happened in the past.

Next, you can add in the concept of state to a component. For each component, props are passed down from the parent and the state lives within that component. If a component is "stateful", this state is persistent between renders for one instance of a component in the interface. State within a component is encapsulated -- the same component can be rendered multiple times throughout an interface with differing internal state. For example, an isHovered state value may be internal to a Button component, controlled by onMouseOver and onMouseLeave event listeners. This stateful behavior is associated with every Button used but will only change the representation of a single instance of the Button which the user hovered over.

// usage
<MyButton onClick={() => console.log("hello world!")}>Say Hello</MyButton>;

// component
function MyButton(props) {
  const { onClick } = props;

  // state to track interaction to make a cool effect
  const [isHovered, setIsHovered] = React.useState(false);

  return (
    <button
      onClick={onClick}
      onMouseOver={() => setIsHovered(true)}
      onMouseLeave={() => setIsHovered(false)}
    >
      {props.children}
    </button>
  );
}

The next logical question is most likely: what if we need some state value to be connected between two components? For example, we have a TextEditor component that stores the current text which is shown. Next, we want to add a Button component with the ability onClick to clear the text in the editor (i.e. interacting with the state of the text editor). In this case, we "Lift State Up". This idea is essentially just that we can raise the location of our state value to the nearest common ancestor within the component hierarchy and then pass down just what the child components need to do their job (e.g. TextEditor gets the text value and a function to update the text when the user inputs text; the Button gets a function to update the text to clear it).

Plain Editor

function MyTextEditor(props) {
  // how could other Components interact with this?
  const [editorText, setEditorText] = React.useState("");

  return (
    <textarea
      value={editorText}
      onInput={event => setEditorText(event.target.value)}
    />
  );
}

Editor with Lifted State

function EditorWithClear(props) {
  const [editorText, setEditorText] = React.useState("");

  return (
    <div>
      <MyButton onClick={() => setEditorText("")}>Clear</MyButton>
      <MyTextEditor
        value={editorText}
        onChange={event => setEditorText(event.target.value)}
      />
    </div>
  );
}

Central State Stores

A pattern seen in multiple state management patterns and libraries is to create a single top-level 'store' of a larger chunk of application state. This can be important when multiple stateful values depend on one another or when your state as a whole needs to have some action performed on it. For example, you may have middleware which tracks or validates updates to this state, or the state may need to be synchronized with an external store using a technology like WebSocket.

From this central store, you pare down the state values passed to each subsection of your application based required or requested information.

This central store is how we transition from a more granular component-level or app-level React state to something which we can synchronize between clients as our single SAGE3 state representation. This central store can contain all of the cross-client state values and be passed down on a per-app basis.

For example, each app has SAGE3 state of the app's position and size, app ID, etc. The size value can be used at multiple places in the component hierarchy: the "Window" component needs the position and size of the app to show up in the proper location of the screen. The specific app implementation may need the size of the app to draw its content responsively and adapt to the screen space provided.

Composition

For the most part, I defer to React's documentation on Composition and Inheritence. Here I will provde an example of how I would compose functionality defined by a SAGE3 app into a general form.

Designing the SAGE3 App

What does a SAGE3 app need?

Based on our current working definition of a SAGE3 app, we can come up with a set of critical information required for an app to exist. I will call this information AppState:

/* context:
  a "DataType" is some recognized type of information within SAGE3
  a "DataReference" refers to a piece of data living somewhere & metadata
*/

type AppState = {
  id: string;
  appName: string; // the name of a distinct SAGE3 app
  position: {
    x: number;
    y: number;
    width: number;
    height: number;
  };
  data: {
    [key: string]: DataReference<DataType> | DataReference<DataType>[];
  };
  // there could be more that we add in the future
};

Everything contained in this representation is synchronized across all users or displays connected to SAGE3. As mentioned above, this AppState information will be used in both the SAGE3 system as well as by the App itself. There are a few ways that an app may use this information.

Image App Components

An app will obviously want all of this information in order to provide proper functionality. Distilled to the most fundamental pieces (and also ignoring some important implementation details), this is how the content of an ImageViewer app may look:

/* context:
  useData(): gets the data based on a DataReference.
  | think of useData as analagous to useState,
  | but allows an app to read and interact with SAGE3 AppState
*/

function ImageViewerContent(props: AppState) {
  const [imageData] = useData(props.data.image);

  return <img src={imageData} />;
}

Aside from the useData(props.data.image) "magic", this app is directly rendering an element based on the AppState passed into the component Similarly, we can allow the ImageViewer to define a dynamic title based on the image filename.

function ImageViewerTitle(props: AppState) {
  const { meta } = props.data.image; // get metadata

  return <strong>{meta.filename}</strong>;
}

To put all the pieces together for this app, we need one file per app which aggregates the export of each of these components if they use multiple files for different components.

/* image-viewer/index.ts */
import { ImageViewerContent } from "./content";
import { ImageViewerTitle } from "./title";

export { ImageViewerContent as Content, ImageViewerTitle as Title };

Text Editor App Components

Just like the ImageViewer app, we could create a simple TextEditor app similar to our EditorWithClear, as well. Here, instead of a dynamic Title we will add a Control for the app.

/* text-editor/index.ts */
function Content(props: AppState) {
  // here, we need the second return value of useData(...),
  // a function to update the data
  const [text, updateText] = useData(props.data.text);

  // just like MyTextEditor from above
  return (
    <textarea value={text} onChange={event => updateText(event.target.value)} />
  );
}

function Controls(props: AppState) {
  const [, updateText] = useData(props.data.text);

  return (
    <>
      <button onClick={() => updateText("")}>Clear Text</button>
    </>
  );
}

export { Content, Controls };

Putting the App into SAGE3

To handle the shared functionality which is common between all app windows, we want a single Window component to which we can pass the app state and the app components to use. The Window component is one that SAGE3 would use, not the individual apps. Each individual app would simply export a component for the Content and optionally one for the Title and/or Controls.

import * as ImageViewer from "./image-viewer";
import * as TextEditor from "./text-editor";

// create an image viewer
<Window appState={myImageState} app={ImageViewer} />;

// create a text editor
<Window appState={myTextState} app={TextEditor} />;

This looks nice and simple, but how can we create this Window component? This component needs to properly compose each of the pieces of the app that we defined. We can do so as follows:

function Window(props) {
  const { app, appState } = props;

  // get the pieces of the app
  const { Content, Controls, Title = () => appState.name } = app;

  return (
    <div className='window'>
      // ~~ render the Title into the titlebar location ~~
      <div className='titlebar'>
        <Title {...appState} />
      </div>
      // ~~ render the Content into the main content area ~~
      <div className='content'>
        <Content {...appState} />
      </div>
      // ~~ if defined, render the Controls into an interface near the app ~~
      {Controls ? (
        <div className='controls'>
          <Controls {...appState} />
        </div>
      ) : null}
    </div>
  );
}

This Window component handles the layout and composition of the subsections making up an app. The HTML layout will position the subcomponents properly and it passes through the appState to each of the components defined for an app so that they can render properly based on the SAGE3 AppState.

Classes vs. Functions

A post about the differences between Function and Class Components written by Dan Abramov (React Core Team) is a good place to start if you are curious about the implementation differences.

Classes in React can be a bit misleading if coming from an OOP background. The class structure is just that - a structure to organize and present common functionality from a component to the React runtime so that the runtime can run lifecycle methods like componentDidMount or componentWillUnmount. This structure follows the Inversion of Control principle where the component can optionally implement methods to handle chosen lifecycle events and React can find and call them when appropriate.

Certain principles of classes from traditional OOP don't align perfectly with the utilization of classes in React. For example, here are a few instances of disconnects between the mental model of classes in OOP and in React:

  1. Class Components are a class but you never instantiate it yourself
  • i.e. new MyComponent(/*...*/)
  1. It extends a class React.Component but not any class you created
  • In practice, inheritance isn't typically used outside of this single situation More on Inheritence

On the other hand, there are a few OOP principles that are core to React:

  • Encapsulation
  • Separation of concerns (or sometimes crosscutting of concerns)
  • Inversion of Control (a broader Software Engineering Principle)

In practice, the usage of Function and Class Components are identical. After all, both are just an encapsulated definition of how some section of the interface will look when it is rendered. Personally, I believe that the Function Component model better reflects some of the principles of React.
